Sounder Bases SIGA-AB4G

The Signature Series AB4G sounder bases add audible output functions to any Signature Series detector. Bases can operate as independent local alarms, or as part of a zone or system alarm with synchronized audible output. Three models provide a full range of features that meet application needs and mandated code-compliant requirements: SIGA-AB4G bases provide sounder capability to Signature Series single-function smoke detectors. They are not intended for use with combination smoke/CO devices in Fire-plus-CO mode. All bases are compatible with first and second generation Signature Series intelligent detectors when properly configured. SIGA-AB4G sounder bases match the finish of Signature Series devices, and the sound output slots complement the air entry openings of the detector. The result is a compact unit with an at- tractive appearance.

•   Low frequency model available Code-compliant 520 Hz output. •   Temporal or steady tone Jumper selects steady or synchronized temporal output. •   High or low dB output Jumper selects low or high dBA output. •   Single or group operation Optional polarity reversing module configures base for group alarm output. •   UL268 and UL464 listed UL listing under smoke detector and audible signal standards allows application as smoke alarm and/or audible signal. •   Attractive installation Flush mount to a wide selection of North American boxes or surface mount to optional custom-matched box.

Riser operating voltage: 16 to 33 VDC Operating Current: The operating current for the Edwards EST SIGA-AB4G sounder base, depending on the voltage (16-33 Vdc or 16-33 Vfwr), ranges from 17 mA to 66 mA (RMS) Supervisory Current: DC = 1.46 mA, FWR = 2.15 mA Default Output Volume: High dBA Default Tone: Temporal Resonant frequency: 3.2 kHz Temporal pattern: 0.5 s on, 0.5 s off,0.5 s on, 0.5 s off, 0.5 s on, 1.5 s off, repeat cycle Compatible detectors: All Signature Series detectors Compatible electrical boxes: AB4G-SB surface box for audible base; 4 in. square by 2-1/8 in. (54 mm) deep box; 3-1/2 in. octagonal by 2-1/8 in. (54 mm) deep box; Standard European 100 mm² box Wire size: 12 to 18 AWG (0.75 to 2.50 mm²) Base diameter: 6.8 in. (173 mm) Base height from box: 0.8 in. (21 mm) Maximum distance from ceiling Wall mount: 12 in. (305 mm) Environment type: Indoor only Operating environment Temperature Relative humidity: 32 to 120°F (0 to 49°C) 0 to 93% noncondensing Storage temperature: −4 to 140°F (−20 to 60°C) Listings: UL, ULC, CSFM
