FS140 | Siemens Surge Protector
Siemens · HMIs & Displays
Description The Siemens FS140 is a surge protector designed for total home protection , featuring a surge spike capacity of 140,000 amps . Installed at the load center , it acts as a commercial-class surge protector to prevent surges from entering the home . Key features of the FS140 include an audible alarm and protection status LEDs , providing clear indications of its operational status . In the event of a problem or the need for replacement , the FS140 eliminates guesswork by emitting an audible alarm , extinguishing the green LEDs , and flashing the red service light . Technical Specifications Applications For Residential use Connection Type Wired Frequency 50/60 Hz Nominal Discharge Current 140 kA Number of Phases 1 Phase Operating Temperature -40 degrees C (-40 degrees F) to +60 degrees C (+140 degrees F) Response Time 1 Nanosecond Size 8L x 4H x 3W TC Connection Wired Temperature Rating -40 degrees C to 60 degrees C Terminal Type Wired Voltage 120 Volt Information About FS140 The Siemens FS140 Firstsurge Power Total Home Surge Protective Device is a commercial-class surge protector designed to safeguard residential electrical systems. With a surge spike capacity of 140,000 amps, it effectively protects against power surges, ensuring the safety of connected appliances and devices. Installed at the load center, the FS140 intercepts surges before they enter the home, mitigating potential damage to sensitive electronics. It features an audible alarm and protection status LEDs, providing clear indications of its operational status. In the event of a problem or the need for replacement, the FS140 eliminates guesswork by emitting an audible alarm, extinguishing the green LEDs, and flashing the red service light. This alerts users to take necessary action promptly, ensuring continued protection of the electrical system.
Brand: Siemens · Category: HMIs & Displays
Specifications
| Manufacturer part number | FS140 |
|---|---|
| Applications | For Residential use |
| Connection Type | Wired |
| Frequency | 50/60 Hz |
| Nominal Discharge Current | 140 kA |
| Number of Phases | 1 Phase |
| Operating Temperature | -40 degrees C (-40 degrees F) to +60 degrees C (+140 degrees F) |
| Response Time | 1 Nanosecond |
| Size | 8L x 4H x 3W |
| TC Connection | Wired |
| Temperature Rating | -40 degrees C to 60 degrees C |
| Terminal Type | Wired |
| Voltage | 120 Volt |
| Product type | Surge Protector |
