Apollo Multi-Sensor Detector (Optical/Heat) 58000-700APO

The Discovery Multi-Sensor Detector consists of optical smoke and thermistor temperature sensors which give a combined signal for improved false alarm management. Reliable fire detection in areas with a very wide temperature range from -40°C to +70°C Five operating modes for customised fire detection and enhanced false alarm management Drift compensation to ensure constant sensitivity A great alternative to Ionisation detectors

GeneralWarranty                                      10 year Applications Bedrooms Hospitals Hotels Medium to large buildings Offices University campuses Clean rooms Warehouses B&Bs/guest houses Cafes Care homes HMOs Restaurants Small to medium buildings Fire Type                              Fast and slow burning fires Wireless                               No PerformanceHeat classification                      A1R Analogue value nominal                 23 Analogue value (- tolerance)              0 Analogue value (+ tolerance)              4 Analogue value                          23 +4/-0 Alarm level analogue value               55 Chamber type                           Chevron MechanicalColour                                  White Sensor configuration                     Horizontal optical bench housing infra-red                                             emitter and sensor, arranged radially to detect                                          forward scattered light. Weight                                 105g Materials housing                       Polycarbonate Materials terminals                      Nickel plated stainless steel Product diameter                        100mm Detection principlePhoto-electric light scattering. Temperature sensitive resistance. Product diameter                        3.94in Product height (wo/base)                 50mm ConformanceStandards EN 54-5 EN 54-7 Approvals FG SBSC BOSEC LPCB VdS CPR ElectricalProtocol voltage                           5 to 9V peak to peak Protocol voltage (max)                     9V Protocol voltage (min)                      5V Power-up surge current                     1mA Maximum power-up time                   10 seconds Status indicator – Alarm                     Red Quiescent current                          470μA Quiescent current tested at                  24V dc Supply voltage (max)                       28V dc Supply voltage (min)                       17V dc Supply voltage (Vmin-Vmax)                17 to 28V dc Terminal functions L2                      +L2 Loop in & out positive Terminal functions L1 in                    +L1 in Terminal functions L1 out                   +L1 out Polarity                                   L1 & L2 are polarity insensitive EnvironmentalHumidity (max)                            0% RH Humidity (min)                            95% RH Humidity Note                             no condensation or icing Humidity                                  95% to 0% (no condensation or icing) Operating temperature                      -40 to 70°C Operating temperature (max)                70°C Operating temperature (min)                -40°C IP rating Value                              IP44 Operating temperature (min)                 -40°F Operating temperature (max)                158°F Operating temperature                      -40 to 158°F
